American telegraphy and encyclopedia of the telegraph; systems, apparatus, operation (1909)
Maver, William, jr. [from old catalog] · New York, Maver publishing company · leaf 313
EDISON-SMITH DUPLEX. The neutral relay is placed in the circuit of battery b, within the contact points,cc oi the pole-changer, so that it is not affected by the reversals of the battery, thedirection of the current between those contacts being always the same. The relays nr, pr are wound singly.…
Telegraph
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
