American telegraphy and encyclopedia of the telegraph; systems, apparatus, operation (1909)
Maver, William, jr. [from old catalog] · New York, Maver publishing company · leaf 478
revolves with it. sl is the shift lever of the ticker. pl is the printinglever. Both levers are mounted on a common shaft x. The right end of sl is slot-ted as shown. The crank roller R is placed in this slot. At its left end sl carries a3-armed shifter f, which is shown more clearly in Fig. 304.… … THE PHELPS stock PRINTER-THEORY. the left end of pl is carried a swinging frame, or fork, /, which latter carries a slidingshaft h^ on whicti the printing pad s^ and two discs d, employed in connection withthe shifter, are placed. On the type-wheel shaft k, //are two pins that assist inshifting the…
Telegraph
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
