Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices"; (1917)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The Norman W. Henley publishing company · leaf 202

An illustration from Mechanical applicances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical mvements, powers and devices";, 1917, leaf 202
eworm gear meshed to a small worm gear on the propeller shaft—steeringis by the bicycle handle and cross arm below, with wire lanyards to therudder. 498. BICYCLE GEAR FOR A BOAT. The sprocket wheelshaft with a large bevel gear drives a vertical shaft with two bevel gears and a fly wheel.…

Mechanical movements
