hould safely clear the rackteeth just as the gathering pallet G lets go of a tooth. Ifattention is paid to this point in adjusting the rack tailthere will generally be little trouble. THE MODERX CLOCK. 3^5 The cam bearing the pins J K on the center arbor may beshifted with a pair of pliers to… … Fig. 109. Train about to strike the half hour; the hook 1/free of thetrain, which is held by the warning pin O ; one stroke will be givenwhen M drops. this hammer tail is very short, and if the spring is strongthe pins may not be able to lift the hammer tail withoutsufficient run to get the train…
Clocks and watches
