American telegraphy and encyclopedia of the telegraph; systems, apparatus, operation (1909)
Maver, William, jr. [from old catalog] · New York, Maver publishing company · leaf 531
wheel, by meansof a strip of rattan f, which substance, singularly enough, has been found the mostsuitable for this work, m is the manually operated rod referred to in connectionwith Fig. 325/^. This rod is provided with a frictional locking device at its left endA, which holds it in a given… … BUCKINGHAM PRINTER—SIDE VIEW. teeth of a small star-wheel, / in otherfigures, are caused to mesh into theseholes, j is the priuter escape-wheelcontrolled by the printer escape-mag-net m. On the same shaft with j{see Fig. 325^) there is a spur-wheeli, which gears with a pinion k, thelatter on a…
Telegraph
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
