find that new properties appear. Indeed both the linksb and d immediately attached to the fixed link a are capable of com-plete rotation. We may accordingly call this mechanism a double-crank linkwork. This is represented in Fig. 58, the links being of thesame sizes as before, KL being now the… … Fig. 58. Double-Crank Linkwork. left sideswritten— c^a+b-dand c<^a+d-b ... (9)respectively. Andthese are equivalentto the inequalities (6)of article 148. It may be furtherseen from the figure(1) that the linkworkin the lower part ofitsrevolutionsassumesthe crossed form showndotted by KLMN, and…
