Appletons' cyclopædia of technical drawing : embracing the principles of construction as applied to practical design ... (1896)
Worthen, W. E. (William Ezra), 1819-1897 · New York : D. Appleton · leaf 285
Fio. 589. in the box, Babbitt, or some other soft metal melted, is poured in round theshaft, and in this way accurate bearing surfaces are obtained; projections orholes are made in the box to hold the metal in its position. The box is sus-pended by lugs b, on gimbals c, similar to those used for…
Mechanical drawing
