Twentieth century hand-book for steam engineers and electricians with questions and answers; a practical non-technical treatise .. (1913)

Swingle, Calvin Franklin, 1846- [from old catalog] · Chicago, F. J. Drake & company · leaf 486

An illustration from Twentieth century hand-book for steam engineers and electricians with questions and answers; a practical non-technical treatise .., 1913, leaf 486
Fig. 167 the cord is returned by the helical spring A, Fig. 168, con-tained in the horizontal spring case B. Adjustment of thisspring is made by the milled head which closes the outerend of the case and carries one end of the spring. Thishead slips over the squared end of the horizontal shaft D,… … ( Fig. 168sectional view of crosby reducing motion the web and gear I of the small sheave are a part of theliorizontal shaft. On this small sheave are the bushings J 474 Steam Engineering which are taken ofi or added tO;, to get the proper ratio ofmotion for the paper drum. The bushings are held in…
