FIG. 1671. h … FIG. 1670. FIG. 1672. generally pointed, but sometimes circular; in the earlier, the angles in whichthe shafts are placed are rectangular; in the latter, the shaft is often mouldedon a chamfer plane—that is, a plane inclined to the face of the wall, generallyat an angle of 45° ; often the chamfer…
