instead of between the lines. This can be conveniently done, when a number of diagramsare to be used, by laying off the spaces on a piece of card-board shaped like A, Fig. 2395, made alittle longer than the average length of the diagrams, so that it may be conveniently applied betweenthe lines B C… … drawn from the same parallel to those at the end. Ten points may be similarly arranged in a pieceof wood, and all pricked into the paper at one time. The multiple parallel ruler, shown in two posi-tions in Figs. 2396 and 2397, is furnished by the Messrs. Elliott Brothers with the Richards…
