form of this lathe is a device for adjusting the fit of the tail-stock spindle without employ-ing any parts save those necessary to the locking device. The manner of accomplishing this is shownin Fig. 25S9, in which A represents the tail-stock spindle, and B the socket, with a clip shown at Cfor… … the socket a proper working fit to the spindle, after which the stud D remains in a fixed position.To lock the spindle, the handle G is used, thus forming a neat and effective device. The Whiiworth Duplex Lathe.—Fig. 2590 is a cross-sectional view (through the slide-rest andshears) of a Whitworth…
