alve Tis attached to this half hinge d by the bent wire e. A connection is made between this bentwire e and the stop-lever X by the link or toggle y. On the upper side of the stop-lever X ismounted a brass incline <j. The transverse lever b consists of a rod of wood, having at each end anarm,… … blocks x. The stops represented in the figures are duplicates of each other. One of them is drawn,or out, and is represented as being connected with the valve P at the back of the tube-board R. After the closest fit possible in the ordinary processes of manufacture, and consistent with thefree…
