Appletons' cyclopaedia of applied mechanics: a dictionary of mechanical engineering and the mechanical arts (1880)

D. Appleton and Company, Benjamin, Park, 1849-1922 · New York, D. Appleton · leaf 555

An illustration from Appletons' cyclopaedia of applied mechanics: a dictionary of mechanical engineering and the mechanical arts, 1880, leaf 555 — 532 PHOSPHOR-BRONZE. … against short pieces of rubber tubing which lie between the plate and a spring attached to E. Theend of this spring carries a rounded steel point P, which enters slightly between the threads scoredon the cylinder C. The distance of this point P from the cylinder is regulated by a set-screw S,…

Mechanical engineering -- Dictionaries

Internet Archive · Boston Library Consortium · Public Domain Mark 1.0. Free to use for anything.
