Appletons' cyclopaedia of applied mechanics: a dictionary of mechanical engineering and the mechanical arts (1880)

D. Appleton and Company, Benjamin, Park, 1849-1922 · New York, D. Appleton · leaf 749

An illustration from Appletons' cyclopaedia of applied mechanics: a dictionary of mechanical engineering and the mechanical arts, 1880, leaf 749 — s the work is released from the dies, the rod P pushes it forward and against the adjusted stop in the revolving head. The details of the revolving head are shown in Figs. 3782 and3783, of which Fig. 3782 is a sectional side elevation, and Fig.3783 a plan. The head or turret revolves upon a pivoted… … moves the slide D. In Fig. 3782 the bottom of the turret is shown, provided with a device having sixprojecting pieces or lugs. As this is fitted into D at c, and as S is a stationary catch, each time the 3783.

Mechanical engineering -- Dictionaries
