Appleton's cyclopædia of drawing, designed as a textbook for the mechanic, architect, engineer, and surveyor (1866)

Worthen, William Ezra, 1819-1897, [from old catalog] ed, Appleton, firm, publishers, New York. (1866. D. Appleton & co.) [from old catalog] · New York, D. Appleton and company · leaf 192

An illustration from Appleton's cyclopædia of drawing, designed as a textbook for the mechanic, architect, engineer, and surveyor, 1866, leaf 192
DRAWING OF MACnDTERY. 149 Fig. 244 is a rigid sleeve coupling for a cast iron shaft; it consists of asolid hub or ring of cast iron hooped with wrought iron ; tlie shafts aremade with bosses, the coupling is slipped on to one of the shafts, the ends … Fig. 242. of the two are then brought together; the coupling is now slipped backover the joint, and firmly keyed. This is an extremely rigid connection. 11

Mechanical drawing · Architectural drawing · Projection · Perspective
