Modern locomotive engineering, with questions and answers .. (1913)
Swingle, Calvin Franklin, 1846- [from old catalog] · Chicago, F. J. Drake & co · leaf 373
Figure 167 Monitor, Interior View the spmdle outside the steam chamber, diminishing itswear. The packing can be adjusted and tightened bymeans of a large central nut, still preserving the sim-plicity and convenience of an ordinary stuffing box. The water valve has been provided with a doublehandle… … INJECTORS, STEAM GAUGES, ETC. 367 Description of *88 Monitor, Fig. 168. This injector isa modification of the well-known locomotive injectorof that name, and is designed to supply the demand fora lever-handled injector, and embody in a new combina-tion all the best qualities of the former…
Locomotives
