Appleton's cyclopædia of drawing, designed as a textbook for the mechanic, architect, engineer, and surveyor (1866)

Worthen, William Ezra, 1819-1897, [from old catalog] ed, Appleton, firm, publishers, New York. (1866. D. Appleton & co.) [from old catalog] · New York, D. Appleton and company · leaf 289

An illustration from Appleton's cyclopædia of drawing, designed as a textbook for the mechanic, architect, engineer, and surveyor, 1866, leaf 289
DRAWING OF MACHINERY. 203 thence by tlie upper steam port m into the upper part of the cylinder; thepiston therefore descends, and the engine commences its in-door stroke. Third ; Y^5 situated in the middle of the nozzle, is the equilibrium valve.WJien this valve is opened the steam above the…

Mechanical drawing · Architectural drawing · Projection · Perspective
