if seven lines be(fig. 61) ruled, enclos-ing six equal spaces, and the length be divided into primaries, as AB, BC,tfcc, the first primary AB may be subdivided into twelfths by two diagonals/I (; ji f running from 6, the mid- die of AB, to 12 and 0.We have here a very con-venient scale of feet and… … DRAWING INSTRIIMENTS. 19 C on tlie several parallels to the various intersections of the diagonals, weobtain 1 foot and any number of inches from 1 to 12. Plotting scales and rulers are scales of equal parts, with the divisionsplaced on a fiducial edge, by which any length may be pricked off on to…
