usted laterally by the set-screws. Fig. 584 is a front elevation of the back-plate cast on the post; it willbe seen that the holes are oblong, to admit of the vertical adjustment of thebracket. The Sellers pillow-block (Figs. 579 and 580) maybe used for the samepurpose. For Upriglit… … ,^/U^ Fig. 585. ened to the base on which it rests ; in the case of heavy shafts, often to a baseof granite. The box B is placed on A, the bearing surface being accuratelylevelled, and fitted either by planing or chipping and filing ; the bearing sur-faces b are commonly called chipping-pieces,…
