Worthen, William Ezra, 1819-1897, [from old catalog] ed · New York, Appleton · leaf 29
Fig. 34. and from C, with radius C F, draw the arc H F G, which will be the arcrequired. To fill up the angle of a straight line and a circle^ luith a circular arc of agiven radius (Fig. 34). On the centre C, of the given circle A D, with a radius 0 E equal to thatof the given circle plus that of…
Mechanical drawing
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
