Worthen, William Ezra, 1819-1897, [from old catalog] ed · New York, Appleton · leaf 297
ron disks A engage with solid keys on the long bossof the spur wheel E, within which the driving shaft C turns freely when nocoupling pressure is applied to the disks. The drum D containing the six in-termediate wood disks B slides on feathers on the shaft 0, and the groove G- onthe outer end of…
Mechanical drawing
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
