Worthen, William Ezra, 1819-1897, [from old catalog] ed · New York, Appleton · leaf 425
of the cranks. The loose eccentric 0 is suspended by the arm c from thepin fZ, around which it has a motion of adjustment; B B are the governorweights, pivoted on the pins l b; one of the weights is connected to the ec- 408 MACHINE DESIGX AND MECHANICAL CONSTRUCTIONS. centric by the link /, and… … Fig. 978.
Mechanical drawing
