Worthen, William Ezra, 1819-1897, [from old catalog] ed · New York, Appleton · leaf 855
thenoise of the machinery annoying the patients in Bellevue Hospital, which is du-ectlyacross the street. Fig. 1871 is a cross-section of the entire structure. Loop System.—The main steam and exhaust piping is shown in plan on Fig. 1872. A16-inch header is run the length of the boiler-room, and a… … APPENDIX. 803 valves, and each section of the boiler-room header is connected to the corresponding sec-tion of the engine-room header by a 14-inch branch rising from the top of one and dis-charging into the top of the other, a valve being placed on each end where a connectionis made to the header.…
Mechanical drawing
