«n Jt-^ «i imL BOILERS. 123 The Locomotive Boiler (Fig. 412) represents a section of a common locomotive boiler, and fig. 413,is an end view of one-half of the smoke end. The proportions of locomotives are considerably variedby different makers, but the general arrangement is always preserved. The…
