Scale.—l-llth inch = 1 foot,Horizon Section through Horizontal Section throughFurnaces. Flues. … Scale.—l-llth inch =s 1 foot.Transverse Sections. 10 146 BOILERS. boilers, with three furnaces in each, making 12 furnaces in all. Length of each boiler, 13 6; breadth,9 10; height, 14 11*. There is a fore-and aft passage between the boilers, 2 feet wide, and anathwart passage 18 inches wide.…
