Pattern making; a practical treatise for the pattern maker on wood-working and wood turning, tools and equipment, construction of simple and complicated patterns, modern molding machines and molding practice (1916)

Ritchey, James, Monroe, Walter W. (Walter William), b. 1869 · Chicago, American technical society · leaf 185

An illustration from Pattern making; a practical treatise for the pattern maker on wood-working and wood turning, tools and equipment, construction of simple and complicated patterns, modern molding machines and molding practice, 1916, leaf 185
Section on line B-3 End View Fig. 288. Working Drawing of Cap for Hanger Bearing side of each piece, and using only very dry and sound stock. Dressthe glued stock to a parallel thickness and width. The width shallbe equal to d, the height c, and the length e. The edges shall bedressed square with…
