Appleton's dictionary of machines, mechanics, engine-work, and engineering (1861)
Appleton, firm, publishers, New York. (1852, D. Appleton & Co.) · New York : D. Appleton · leaf 297
c a a \ VA … ^ yjf^-< Literal References—A, the saw-frame, with the saw b b attached to itB B, the fast and loose pulleys on the saw-frame shaft C, the log which is to be cut into veneers. D, the timber-frame to which the log is attached. E, the cast-iron frame to which D is bolted, which slides laterally…
Mechanical engineering
