fly-wheel into C... 1st pair of small bevels2d do. do.... Diameter of the millstones, 4 feet. Literal References to Fig. 1004. A, the great bevel-wheel on the crank-shaft of first engine. B, the pinion on the mill-shaft working into the above. C, a spur cog-pinion on the mill-shaft driven by the… … CORN-SHELLER. 341 a a a, the bevel wheels and pinions for driving the mill-spindles.b, a strong bracket for strengthening the bearing of the pinion B.e c, two cast-iron cross-stays for the same purpose.ddd, the feeding hoppers.eee, the frames supporting the feeding hoppers.///, the cast-iron…
