Technology of textile design. Being a practical treatise on the construction and application of weaves for all textile fabrics, with minute reference to the latest inventions for weaving. Containing also an appendix showing the analysis and giving the calculations necessary for the manufacture of the various textile fabrics (1889)

Posselt, E. A. (Emanuel Anthony), 1858-1921 · Philadelphia, Pub. by the author [etc.]; London, S. Low, Marston, Searle & Rivington, limited · leaf 187

An illustration from Technology of textile design. Being a practical treatise on the construction and application of weaves for all textile fabrics, with minute reference to the latest inventions for weaving. Containing also an appendix showing the analysis and giving the calculations necessary for the manufacture of the various textile fabrics, 1889, leaf 187 — g-fliers positive. As before stated, there are in the machine shown in the drawing, Fig. 826, six of the horizon-tal whirls, three of which drive the coiling-fliers, the other three driving the uncoiling-fliers.These latter resemble the coiling-fliers in shape, having uprights connected by bottom…

Textile fabrics

Internet Archive · Clark Art Institute Library · Public Domain Mark 1.0. Free to use for anything.
