Appleton's dictionary of machines, mechanics, engine-work, and engineering (1861)
Appleton, firm, publishers, New York. (1852, D. Appleton & Co.) · New York : D. Appleton · leaf 374
the position of the rope No. 1, it will be seen that by it the right hand one of DERRICK. >367 these blocks can be raised or lowered by means of the crank, pinion, geer and barrel. No. 1 of thecrab, at the opposite end of the boom; in a similar way, the left hand block is raised by rope No.… … Scale.—6 feet=l inch. •inwards. Again, if rope No. 1 alone be slackened, the weight is lowered and tends inwards, and again ifNo. 2 be slackened, the weight is lowered outwardly ; by these means the stone may be deposited atany spot within reach of the boom.DISC ENGINE. See Engine. 368.…
Mechanical engineering
Internet Archive · Smithsonian Libraries · Public Domain Mark 1.0. Free to use for anything.
