s put in with pins; and the slot is on the incline, to prevent a rut in the cylinder. The tongue-pieces,of this and the preceding variety, are of course ground in, a piece being ground on the back to preventthe steam from passing. This species of piston ring is probably among the best yet… … Scale.—i inch=l foot. Fig. 1557 represents the piston often used for cylindrical slide-valves. By raising or lowering thescrew, it will be evident that the rings are compressed or expanded. A flat place is of course cast inthe body of the piston to leave room for the bridle. 1554.
