working on h. H, the cross-head, h, the crank on the main driving shaft i. i, the main driving shaft, j, balance wheel. h k, the main bevel wheel geering, transmitting the power from the main driving shaft i to thelongitudinal driving shaft I. I, longitudinal drivhag shaft working the thrusting… … o, pulley or wheel on shaft / for setting in action the pumping apparatus, and connected by a belt with p. p, pulley or wheel driving the pump shaft r.q, a movable pulley for tightening or loosening the belt connecting o and p.r, a crank shaft working the pump rods t. s, a balance wheel on the pump…
