sized pipes to a scale of 1J inch to one foot. Fig. 1948 is thatof mains from nine to fifteen and eighteen inches diameter. The usual thick-ness of metal is shown by the hatched lines, and is proved to be sufficient.The depth of these sockets is 4-J- inches. Fig. 1947 is a section of the sockets of… … 1946. 1947. 1948.
