. 1986, 1987, another form of geer-cutting engine for cutting bevel, spiral, and spur geers, alsomade by the Lowell Machine Shop. Fig. 1986, side elevation. Fig. 1987, front or end elevation. E E are the end standards which form part of the frame. D, swing slide, in which the cutter head slides… … 0, handle nuts for fastening the swing slide in the circular slot at any angle required. A, driving pulley on the shaft that drives the cutter shaft. This pulley and shaft are fixed. Thecutter shaft can be taken out without throwing off the belt, as the two shafts are connected togetherwith a…
