Appleton's dictionary of machines, mechanics, engine-work, and engineering : illustrated with four thousand engravings on wood ; in two volumes (1873)
D. Appleton and Company · New York : D. Appleton and Co. · leaf 135
9, used for steamboat Troy, built by T. F. Secoe and Co., bas tw«ingines of 44-inch cylinder, and 10 feet stroke. Uses anthracite. Fire surface in this boiler. Front of furnace 1890 Sides of ditto pOO Top of ditto 76-50 Bridge-wall 18-00 Between bridge-wall and flues 2000 Between flues, back and… … BOILERS. 133 Figs. 430 and 431. The steamboat Globe, built by T. F. Secor and Co., has one engine of 41mch cylinder, with 11 feet stroke. 100 cubic feet in the cylinder, which gives 10TA to 1.Uses anthracite coal, with a blower.
Mechanical engineering · Mechanics · Engineering
Internet Archive · Public Domain Mark 1.0. Free to use for anything.
