ure stages of theCurtis type not only replaces the small-area reaction stages in whichleakage is of serious magnitude, but also makes easy an arrangementwhich is more or less self-balanced — see Fig. 26. The double-flowsystem, represented by Fig. 357, still further facilitates the eliminationof end… … MO JO ^ 02 P bO § 50 id)] VARIOUS FORMS OF THE TURBINE. 515 from the middle toward the ends, thus requiring two stuffing boxestight against leakage of air into the condenser, just as in Fig. 25.For low-pressure service, the impulse stages are naturally omitted;then flow from the ends toward the…
