bearings in plummer-blocks attached to the frame A, and have hand-wheels n n at their lower ends.The plates//have lugs o o fastened on their inner ends, which lugs work upon shafts pp, and so formcentres for the circular motion of the pjlates // The plates // are provided also underneath withguides… … The slidiug-frame K being placed at one end of the machine, so that the screw 11J js in the samevertical line with the shaft I, the pressing-block M1 being raised close under the top of the frame K,(see dotted lines in Fig. 4005,) the blank required to be shaped into a stave is placed in the frame…
