Appleton's dictionary of machines, mechanics, engine-work, and engineering : illustrated with four thousand engravings on wood ; in two volumes (1873)
D. Appleton and Company · New York : D. Appleton and Co. · leaf 412
seach side of pinion-geer g, pressure to which is given by a small hand-wheel, the quantity of feed canbe raised so as to suit the size of the hole to be drilled. The circular table F F on which the work to b» DRILLING-MACHINE. 40j orilled is laid, is prevented from turning round by means of a stop… … Scale.—2 fect=l inch. A machine of gigantic dimensions has been constructed by Nasmyth for the Great Western SteamNavigation Company. In this machine, the entablature carrying the upper end of the boring-bar is supported on twomassive pillars of masonry, placed one on each side of the boring-bar.…
Mechanical engineering · Mechanics · Engineering
