Bradbury, F. (Fred) · Manchester : John Heywood Ltd. · leaf 113
are two cam slides connected through the adjustable links f, f1to the draw rods g, g1 respectively. 1, i1 are antifriction rollersbetween which the slides e, e1 can reciprocate. Mounted and freeto rotate upon studs secured to the cam slide plates e, e1 are anti- io8 JACCjUARD MECHANISM AND HARNESS… … Fig. 103. Fig. 104. Action of theMechanism. The reciprocation of the draw rods g, g1 is asfollows :—With the constant rotation of the lowshaft b, the cam d rotating counter clockwise,presses upon the roller j to depress the cam slide,the link f and the draw rod g to produce the upper division of…
Textile machinery
Internet Archive · Smithsonian Libraries · Public Domain Mark 1.0. Free to use for anything.
