Appleton's dictionary of machines, mechanics, engine-work, and engineering : illustrated with four thousand engravings on wood ; in two volumes (1873)
D. Appleton and Company · New York : D. Appleton and Co. · leaf 936
ixed. A substantial foundation, consisting of stone-work, isprepared for receiviug the two frames a a, and to which they are firmly bolted down by strong hold-ing-bolts. GRINDING MILL. 933 Another mode of performing this same operation might be adopted, by fastening a -whole grindstoneinto the… … References to Figs. 2201, 2202, and 2203. <r, cross-frames or standards. 6, Longitudinal frames. c, Bed-plates. (A, Cro^s-slides. e. Slides or face-plates for earning work. /, Grindstones. g, Driving-riggers. A, Rods for reversing motion by means of tappet h and i, Clutches. [clutches i. j.…
