circle indicates the position of the fly-wheel,by which the power is equalized on the crank; and the shaded lines show the jaws, which arc separateplates of wrought or cast hon, bolted on tlie frame, and renewed when necessary. Such a machine,making from 80 to 90 revolutions per minute, can squeeze… … A different apparatus from this, and free from some of its defects, is Burdens patent eccentric rotarysqueezer—the mode of whose action will be apparent from the projection in Fig. 2-107, where r showsa cyhnder with a roughened or serrated surface, revolving vertically in an eccentric drum which is…
