inside of the bed-piece,and not shown in the drawing. 0, geer on end of feed-screw, driven by a pinion on the hub of the lower feed-cone D. A, cone-pulleys on spindle of cast-iron. r, face-plate with geer B attached to the back side. K, tool-holder, which slides upon a swivel-post S, that can be… … G is a hand-wheel for traversing flie rest by handcraft. This wheel runs on a stjd, with a pimon onits hub whicli works into the geer H. H is placed on the end of a short shaft with a pinion A on theother end, geering into the rack I attached to the side of the bed. T is the main slijing-saddle or…
