Appleton's dictionary of machines, mechanics, engine-work, and engineering : illustrated with four thousand engravings on wood ; in two volumes (1873)
D. Appleton and Company · New York : D. Appleton and Co. · leaf 276
udinal section of the engine, showing the internal arrangements of the boiler, and the working parts of the engine. Fig. 2606, a sectional plan of the engine, with the cylindrical part of the boiler removed, for thepurpose of exliiLiiting the general arrangement of tlie working piuts, and the… … The following figures represent end elevations and transverse sections of the engine Fig. 2609, an elevation of the engine as seen at the fijre-box end. Fig. 2610, a transverse section through the fire-box. Fig. 2611, an elevation of tlie engine as seen at the smoke-box end. Fig. 2612, a transverse…
Mechanical engineering · Mechanics · Engineering
Internet Archive · Public Domain Mark 1.0. Free to use for anything.
