Appleton's dictionary of machines, mechanics, engine-work, and engineering (1869)
New York, Appleton · leaf 279
Fig. 2619, a side view of the same.Fig. 2620, an end view of the same.Fig. 2621, an elevation of the backward eccentric. Fig. 2622, a plan of the same, showing the stud for working the expansion-geer.Fig. 2623, a side view of the reversing or coupling link. Fig. 2624, an edge view of the same,…
Mechanical engineering
Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
