Appleton's dictionary of machines, mechanics, engine-work, and engineering : illustrated with four thousand engravings on wood ; in two volumes (1873)
D. Appleton and Company · New York : D. Appleton and Co. · leaf 28
he moving-jaw k. It will be observed that when the moving-frame// has per-formed its forward motion, then the cam m strikes against the stop n, which permits the cam o to openthe moving-jaw k by striking against the stop p, which allows the piece of iron, which may have beenrolled or sliaped to a… … It will be observed that the box u ii u turns on a pin in the moving-frame, which, when the crankpushes back the moving-frame, the head or box part strikes against the pin or piece of u-on w, andpresses up the chisel t against the chisel s, and cuts off the piece of iron to the length intended for…
