Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries (1910)

Hiscox, Gardner Dexter, 1822?-1908 · New York, The N. W. Henley publishing company · leaf 115

An illustration from Mechanical appliances, mechanical movements and novelties of construction; a complete work and a continuation, as a second volume, of the author's book entitled "Mechanical movements, powers and devices" ... including an explanatory chapter on the leading conceptions of perpetual motion existing during the past three centuries, 1910, leaf 115
114 EXPLOSIVE MOTOR POWER AND APPLIANCES. :m … 267. COMBINED GASOLINEAND STEAM MOTOR. In this de-sign the piston of the explosive motor ismade the crosshead for the connectingrod. A duplex steam engine with aduplex explosive motor as an auxiliary-power in which the exhaust of the steamengine may also be turned into the ex-plosive motor cylinder…

Mechanical movements

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
