g. 2657, section.Vol. IL—19 290 LOOM, DOUBLE-STROKE. Fig. 2659, illustration of the movement -which operates the picker-staffiFigs. 2660 and 2661, shuttle. Fig. 2658, elevation of the loom on the side of the warp.Figs. 2662 and 2663, plan and section of the brake.Fig. 2664, plan of one of the… … threads of the warp. E E, harness for raising and lowering the threads of the warp for the passage oithe shuttle. F, breast-beam. 6, cloth-beam. H, spur-wheel on the shaft of tlie cloth-bcam. /, pmionworking into the wheel H. I, ratchet-wheel, which works with the pinion. J, bell-crank, moving…
