emainder runs to waste by the pipe e.The steam is admitted to the cylinder when the piston is on the centre, and is allowed to escape tc 358 MARINE STEAM ENGINE. the eduction-port or blast-pipe when the piston is Ifths inch from the end of its stroke. The valve Sopens to the condenser when the… … At/and (7, two cocks are placed upon the pipe Y, leading to the condenser, and these cocks are soarranged that when one is open the other is shut. The injection-pipe fi, is placed between the air-pump and the cocks /and </, so that by reversing the latter by means of the rods and levers J:I-,…
