Steam turbine engines : their construction, care and operation (1910)
Swingle, Calvin F. (Calvin Franklin), b. 1846 · Chicago : Frederick J. Drake · leaf 26
iamater, 6 feet. By reference to Fig. 244 it will be seen that the insideof the cylinder is studded with rows of small stationaryblades, and that the rotor or revolving part of the ma-chine is also fitted with rows of small blades, similar inshape and dimensions to the stationary blades. When… … Fig. 245 SECTION OF STANDARD WESTINGHOUSE SINGLE FLOW TURBINE 2? iStcain Eiujinccring understood liy refereme to Fig. *34T, whicli illustrates therelation of the stationary hlades to the niovini; hlades whenin position, and also shows hy tlie arrows the course of thesteam and its cliange of…
Steam-engines -- Design and construction · Steam-turbines -- Handbooks, manuals, etc
Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
