Fig. 2950 and 2954 show two pair of rollers for forming the astragal, to which the upper and lowerplates of the chimney of a locomotive are riveted; the rollers B B are used in the order the draw-mgs are lettered. Fig. 2963 shows a pair of rollers for forming the base mould, and Fig. 2949 for…
